Products Description
Garage door panels is a double-layer composite panel with a total thickness of 40mm-50mm. The panel steel sheet thickness can be 0.35mm-0.6mm. The door side is sealed with 2.0mm galvanized steel track, and the appearance can be customized .
The color steel sheet is first treated with double-sided hot-dip galvanizing: After the cold-rolled steel plate is continuously hot-dip galvanized, the double-sided standard galvanized adhesion is more than 275/m.
Product Specification
|
Products Title |
Garage door panels |
|
Thickness |
40-80mm for choose |
|
Pattern |
One lines or Three Lines. Short or Long Raised . Smooth or Flat with wooden grain |
|
Metal Material |
PPGI(Pre -Painted Galvanized Steel Coil)0.35-0.6mm for choose |
|
Color |
White,RAL 7016,Brown,Silver,Golden Oak,other color could be customized. |
|
Panel Width |
435mm,535mm,485mm,500mm,610mm or Customized |
|
Door Panel Weight |
8.3kg/m2-10.2kg/m2 |
|
Insulation |
PIR Foam with 45KG/M³ |
|
Hardware |
1.5mm galvanized hardware, |
|
Package |
One set door panel for 2 package,door accessories for 1 package |
|
Warranty |
5 Years for panel.2 Years for hardware. |
Factory Workshop
1. Coated Steel Uncoiling
2. Electrostatic Film Laminating
3. Forming of Coated Steel Sheet
4. Double track foam composite
5. Precise machine cutting
6. Panel cooling
7. Stacking
8. Package
Project Cases
Garage door panels: Essential components forming the structure of garage doors, available in various materials and designs for functional and aesthetic purposes.
FAQ
1. What are garage door panels?
Garage door panels are individual sections that, when connected, create the complete structure of a garage door.
2. Can garage door panels be replaced individually if damaged?
Yes, in most cases, individual panels can be replaced without replacing the entire door.
3. Do garage door panels come in different sizes?
Yes, panels vary in width and height to fit different garage door sizes and styles.
4. Can different panel designs be incorporated into one door?
Yes, garage door panels often come in various designs and can be mixed to create a unique style.
5. Are insulated panels available for garage doors?
Yes, many garage door manufacturers offer insulated panels for improved energy efficiency.
6.What's your delivery time and payment term?
Payment Term:30%TT Advance Payment. 70%Balance Payment before delivery.
Deliver Time: 15-20 Days.
