Products Description
Element's Standard 2-Car Garage Door offers ample space tailored for two-vehicle storage, ensuring comfortable access and eliminating concerns over scratches or tight maneuvering. Designed with practicality in mind, the door is available in panel thicknesses from 40–80mm and widths including 435mm, 535mm, 485mm, 500mm, and 610mm-or fully customized to fit. Constructed with 0.35–0.6mm PPGI pre-painted galvanized steel, each panel weighs between 8.3–10.2 kg/m² and is insulated with high-density PIR foam (45 kg/m³). A range of standard colors such as White, RAL 7016, Brown, Silver, and Golden Oak is offered, with custom options available. The door system is supported by 1.5mm galvanized hardware and is backed by a 5-year panel warranty and 2-year hardware warranty. It accommodates operational speeds up to 1.75m/s and supports various raised panel designs, including single or triple-line patterns with wood grain finishes.
| pening Method | Electric Side-Hinged |
| Panel Type | Polymer |
| Surface Finish | Pre-finished |
| Warranty | 5 Years |
| Material | Aluminum |
| Feature | Anti-theft |
| Project Solution Capability | Integrated Solutions |
| After-sales Service | On-site Inspection, Online Technical Support, On-site Installation, Free Spare Parts |
| Design Style | Modern |
| Panel Material | Galvanized Steel |
| Application Scenarios | Garages, Villas, Warehouses, Apartment Buildings, Auto Shops |
Products Workshop
Coated Steel Uncoiling.
The production process begins with the precise uncoiling of pre-coated steel coils. This initial stage requires careful handling to ensure the integrity of the coated surface is maintained, providing a flawless foundation for subsequent processing steps.
Electrostatic Film Laminating
The uncoiled steel undergoes electrostatic film lamination. Utilizing advanced electrostatic adsorption technology, a protective film is permanently bonded to the steel surface. This enhances both corrosion resistance and visual appeal while safeguarding the material during further fabrication.
Forming of Coated Steel Sheet
The laminated steel is then fed into high-precision forming machines. Through controlled roll-forming processes, the flat sheets are accurately shaped into panel profiles that meet exact garage door design specifications.
Double Track Foam Composite
Formed panels proceed to foam injection. Polyurethane foam is rigorously injected under pressure into the double-track panel structure, creating a continuous core that significantly improves thermal insulation and acoustic performance.
Precise Machine Cutting
Finally, the composite panels undergo computer-numerical-controlled (CNC) cutting. This automated process ensures each panel is trimmed to exact dimensional requirements, guaranteeing consistency and perfect fit during door assembly.
Products Case
successful cases
Choose the plan that suits you best.
Project in Australia (Residential)
For a commercial car dealership in Sydney, Element supplied large, automatic aluminum doors. Their corrosion-resistant properties and sleek, glazed design provide an impressive entrance for show vehicles, enhancing both visibility and curb appeal.
Project in Germany (Residential)
A smart home in Munich features Element's thermally broken aluminum garage doors in RAL 7016. They ensure excellent energy efficiency year-round. The minimalist design and frosted glass add a sophisticated, private finish to the property.
Project in (Commercial)
Element's modern aluminum garage doors were chosen for a luxury Vancouver residence. The silver finish and clear glass panels complement the West Coast architectural style perfectly, offering durability against rainy weather while flooding the space with natural light.
Project in UAE (Hospitality)
Element's custom golden oak doors grace a luxury hotel garage in Dubai. Designed to withstand extreme heat, their mirrored glass reduces solar gain while adding a striking, opulent first impression for guests arriving by vehicle
Why choose us?
No.1
1. Superior Track System
Our tracks are roll-formed from high-quality galvanized steel coils using fully automated CNC processes, ensuring industry-leading precision and durability. This results in smooth, reliable operation and exceptional resistance to wear and corrosion, providing long-term performance with minimal maintenance
No.2
2. Durable Torsion Spring System
The spring shaft is made from tempered solid round steel, while the winding wheel is a single-cast aluminum alloy component connected via a flat key. This robust design ensures secure attachment between the shaft and wheel, offering enhanced safety, easier installation, and outstanding resilience under high-frequency use.
No.3
3. Automated Panel Production Line
We use premium raw materials from internationally renowned suppliers such as Bluescope, Baosteel, and Bayer. Our automated production line ensures consistently high-quality door panels with excellent structural integrity, thermal efficiency, and surface finish, providing customers with reliable and aesthetically pleasing products.
No.4
4. Integrated Project Solutions
Element offers comprehensive support from initial AutoCAD design and project planning to production, delivery, and on-site technical guidance. Our integrated solutions ensure seamless execution from concept to installation, providing customers with a hassle-free experience and customized garage door systems that meet exact requirements.
No.5
5. Customizable Glass Options
We provide a variety of glass types including PVB laminated, tempered, insulated, and polycarbonate, available in multiple colors and finishes. These options enhance both safety and privacy while allowing for diverse design possibilities, making it easy to match architectural styles and personal preferences.
No.6
6. Extended Warranty & Support
Element stands behind its products with an industry-leading warranty package: 5 years on panels, 2 years on hardware, and 1 year on motors. This commitment reflects our confidence in product quality and ensures customers receive reliable long-term performance and peace of mind.
Our Certificate
FAQ
Q: Q1: What are the standard sizes for a 2-car garage door?
A: While commonly referred to as "standard," we offer extensive customization. Popular single-panel widths include 435mm, 485mm, 500mm, 535mm, and 610mm. The overall door width is achieved by combining multiple panels. We highly recommend providing your exact rough opening measurements for a perfect custom fit.
Q: Q2: What is the door made of, and how thick is it?
A: The door panels are constructed from high-quality PPGI (Pre-Painted Galvanized Steel Coil), which offers excellent corrosion resistance and durability. You can choose the material thickness (0.35mm, 0.45mm, 0.5mm, or 0.6mm) and the panel thickness (from 40mm to 80mm) to meet your specific insulation and structural needs.
Q: Q3: How is the door insulated, and what are the benefits?
A: Our doors are insulated with high-density PIR foam (45kg/m³). This superior insulating material significantly improves thermal efficiency, reducing energy costs, minimizing noise from outside, and enhancing the overall durability and rigidity of the door panel.
Q: Q4: What color and design options are available?
A: We offer a variety of standard colors including White, RAL 7016 (grey), Brown, Silver, and Golden Oak. Custom colors are also available upon request. For the panel design, you can choose between One-Line or Three-Line patterns, with Short or Long Raised panels, and finishes like Smooth or wood grain textures.
Q: Q5: What is included in the package?
A: The door system comes in a clearly organized package: one package contains all the door panels, and a separate package includes all the necessary galvanized hardware (tracks, springs, brackets, etc.) for installation.
Q: Q6: What kind of warranty do you provide?
A: We stand behind our product's quality with a strong warranty: a 5-year warranty on the door panels and a 2-year warranty on all included hardware.
