Products Description
The Element PU Wall Sandwich Panel is composed of 0.5mm-thick color-coated steel sheets bonded to a polyurethane foam core with a density of 42kg/m³, offering exceptional thermal insulation performance (thermal conductivity of just 0.021 W/m·K). Typically used for the exterior walls of warehouses and factories, it features a specialized joint design that allows for concealed-fastener installation.
The product is available in four thicknesses ranging from 50mm to 200mm, with custom sizing options also supported. It utilizes a convenient concealed-fastener installation method. We provide complimentary installation drawings and a 5-year warranty; should you require installation guidance, we can also arrange for a professional construction team to assist you.
Product Specification
|
Products Title |
PU sandwich panel for wall |
|
PPGI Thickness |
0.4-0.7mm for choose |
|
Panel Thickness |
40/50/75/100/120/150/200mm |
|
Color |
any other required on RAL Color |
|
PU Density |
42kg/m³(±2) |
|
Effective Width |
400-1120mm for wall panel,1000mm for roof panel |
|
Length |
Max 11.85mm for 40HQ container or customized |
|
U Value(w/mk) |
PU:≤0.024 |
|
Fire Rating |
PU:CLASS B1 |
|
Surface Texture |
Flat/Embossed Pattern/V8/Micro Ripple |
|
Application |
Factory panel/cold storage/workshop |
Factory Workshop
PU Sandwich Panel for wall workshop
We have introduced Italian PUMA continuous production equipment for polyurethane composite panels, boasting a daily capacity of 3,000 meters. The entire line is operated by just six personnel, resulting in reduced labor costs, while ensuring precision laser cutting and uniform foam density.
The continuous production line for polyurethane composite panels is equipped with an uncoiler, profiling machine, foaming machine, laser cutting system, and an automatic panel cooling and stacking unit.
Standardized Production
Passed ISO9001 certification and obtained relevant patent certificates.
High-Quality Customized Services
No intermediate links, providing one-stop service from design, processing, mold trial to mass production.
Project Cases
who choose us?
Polyurethane (PU) sandwich wall panels have a wide range of applications across various industries. They are commonly used in industrial warehouses and commercial buildings; in residential buildings, they are used as exterior wall materials, effectively achieving thermal insulation and energy conservation.
Furthermore, they are used in the construction of walls in hospitals and medical facilities, helping to maintain a stable indoor environment, thereby ensuring patient comfort and properly protecting various equipment.
They can also be used in the cold storage industry, offering first-class insulation performance.
We supply free drawing project, and install consulation. 5 years warrany free.
one-stop solution
professional team
high quality
Our Certificate
FAQ
What are PU sandwich panel for wall?
PU sandwich panel for wall are construction materials comprising a core layer of polyurethane foam insulation sandwiched between two outer layers, typically metal or aluminum. They are renowned for their insulation properties.
What are the advantages of using PU sandwich panel for wall?
PU sandwich panel for wall offer exceptional thermal insulation, lightweight construction, moisture resistance, durability, and aesthetic versatility.
Where are PU sandwich panel for wall commonly used?
These panels find applications in cold storage, commercial buildings, residential construction, clean rooms, agricultural facilities, transportation, and industrial buildings.
Are PU sandwich panel for wall eco-friendly?
They are eco-friendly as they reduce energy consumption and greenhouse gas emissions, contributing to a more sustainable environment.
How do I install PU sandwich panel for wall?
Installation involves joining the panels to a supporting structure using appropriate fasteners and sealants. It is recommended to follow manufacturer guidelines for installation.
What's your delivery time and payment term?
At present, our company has polyurethane double crawler molding equipment imported from Italy and polystyrene metal composite plate production.
Production lines, rock wool metal composite panel production lines imported from Germany, C/Z steel production lines and other large production lines are what we serve our customers
A strong guarantee for providing customers with quality services
Payment Term:30%TT Advance Payment. 70%Balance Payment before delivery.
